Application Segments

    Oil & Gas/CPI

    Melting Route

    Airmelted

    Product Description

    BÖHLER N404 is a stainless soft-martensitic Cr steel with 5% nickel with molybdenum addition.
    Due to the higher alloy content, the corrosion resistance of BÖHLER N404 is higher than that of stainless steels of type 1.4313. Due to the molybdenum addition, limited use in the maritime sector is also permissible. As a result of the chemical analysis and its microstructure, BÖHLER N404 is particularly insensitive to intergranular corrosion and very resistant to fatigue and stress corrosion cracking.
    To achieve the best possible corrosion resistance with BÖHLER N404, it is essential to polish the surfaces concerned. Good mechanical properties in the quenched and tempered condition. This makes this material very suitable for use in the oil and gas sector. Very good low temperature properties. Recommended temperature of use: – 60 to 350°C.
    Special heat treatment to max. 23 HRC is required for sour gas enviroment in petroleum engineering.
    Fittings, pumps, compressors, centrifuges, hydroelectric machines, reactor technology, shipbuilding, chemistry, petroleum technology, aviation and refrigeration technology.

    Property Features

    Martensitic chromium stainless steel with 5% nickel addition. Good properties at subzero temperature.

    Technical Specifications

    Material Numbers


    1.4418 X4CrNiMo16-5-1


    Standards


    10088-3

    Chemical Composition

    Chemical composition (average %)
    max. 0.06 max. 0.70 max. 1.50 max. 0.040 max. 0.030 15.0 to 17.0 0.80 to 1.50 4.0 to 6.0 min. 0.020

    Available product shapes

    Information on Long Products ) Presented data refer exclusively to long products. Please observe the detailed explanations at the end of the data sheet (pdf).

    • Long Products

      Long Products

    • Open Die Forgings

      Open Die Forgings

    • Semi-Finished Products / Billet

      Semi-Finished Products / Billet
